Advantage

Feature:

1. Filtering precision: 5-10 Micron.

2. Filtration efficiency: 98%

3. Service life is approximately: larger than 2000h.

4. Used for screw air compressor.

Oil filter
Filter impurities and retain beneficial ingredients

Specially designed bypass valve, compatible with rotor lubricant

Good water resistance and corrosion resistance and strong anti-pulse ability, reliable use

The normal operation of the machine under severe lubrication conditions reduces the risk of failure

oil_filter_details

ANKA Filter chooses the excellent quality materials for all end covers, filter materials, and glue, the highest configuration. The filter material adopts imported American glass fiber, which has a long service life, guarantees the filtering effect, and reduces fuel consumption.

 Machine ModelAir FilterOil Filter Separator
Small UP 88171913 39329602 22388045
 UP5-11/15/22 8929597654672654 54749247
 UP5-30/37 2220309554672654 54749247
M22 OLD 4288821442888198 39751391
M22S395884703990717554595442
M22395884703990717539831888
 ML22395884703990717592890334
 M37 OLD 992739064288819892754688
 M37395887773990717539831888
 M37S395887773990717554595442
 M45397084663991161522089551
 M55-7539708466 39911631 54601513
 M55S-75S39708466 3991163139894597
 M90-110/160 39903281 39911631 54509427
 M90-110/160 39903281 39911631 54509427
M132-16039903281 39911631 54509427
 M200-2503990326592888262 22219174
 M300-350399032659288826254509435
 M250428521299288826239890660
 M110399032813991163188181755
MR ED M200/250 39903265 9288826254509500
MR ED M300/350 39903265 9288826254509435
XF/EP/HP/XP-30SE428554293990717539831888
XF/EP/HP/XP-50SE428554113990717539831888
 XF/EP/HP/XP75-100992670319927013442841239
XF/EP/HP/XP75-100992670314284136142841239
 XF/EP/HP/XP75-100 SE428554034284136139894597
 XF/EP/HP/XP75-100 SE428554034284377154601513
XF/EP/HP/XP75-100 SE42855403428437975601513
 XF/EP/HP/XP 125-200 992667029927406042841247
XF/EP/HP/XP 125-200 9926670299274060 39799578
XF/EP/HP/XP 125-200 99273906 4284380542841247
 XF/EP/HP/XP 125-200 992739064284378939739578
125S/150S/175S/200S39903281 39856836 39863865
M90/M110/M132/M160399032813991163199277998
 M90/M110/M132/M160399032813991163154509427
HPE300397507239288826239863899
 VHP400/600/P60092686948/ 9268695599246092/9392699198
 VHP600/7009203594899274060 92062132
 VHP600/70092035955 99274060 92062132
 S100- 9926703142843797 42841239
 S200-992667024284380542841247
 IR 37PE 22203095  54672654 54749247
 IRN.55-75KW54672530 5467265438008587
 IRN.90-160KW22130023 3991163142542787
 V5.5-11 8817191339329602 22388045
 V15-224685683746853099 46853107
V30-37 4685684546853099 46853107
 125-200S 399032813985683654509427
125-200S 399032813991163139863865
30SE428554293990717539831888
50SE 428554113990717539831888
 70SE/100SE428554034284379739894597
 R5-11 1U881719133932960222388045
 R90-110N,R90-110 I234298222342492223545841
 R132-160NE,R132-160 I2342982223424922 23566938
 R90-160NE,R90-160 IE2342982223424922 23566938
R1602348745723424922 23566938
GA5/7/101503019000 1513033700 1513005800
 GA5/7/10/5C/7C/11C 16139001001613610500 1613901400
 GA5C/7C/11C 161390010016136105001622087100
 GA11/15/18/22161912690016136105001612386900
 GA11/15/18/22161912690016136105001613692100
 GA11/15/18/22161912690016136105001613750200
 GA11/15/18/22/30C161387200016136105001622007900
GA11/15/18/22/30C161387200016136105001622051600
 GA11+/15+/18+/22+161387200016136105001622051600
 GA11+/15+/18+/22+/26+/30161387200016227836001625703600
 GA11/15/18/22161387200016136105001622035101
 GAe11/15/18161387200016257525001625775300
 GAe22/26/30161387200016257525001625775400
 GA30/37161927970016136105001202641400
 GA30/37/45161927970016136105001613688000
GA30/GA37161927970016136105001613839700
 GA37/45/50/55C/50VSD161374080016136105001613839702
GA30+/37+/45+161374080016223142801622314000
 GA30AP/37AP/45AP 161374070016223142801622646000
 GA55/75/90 1619279800 16136105001613730600
 GA55/75/90 1613800400 16136105001613800700
 GA55/75/90C 1613950300 16136105001613984000
 GA55+/75+ 1613950300 16223652001622365600
 GA55AP/75AP162218550116223142001622569300
 GA90AP 161395030016136105001622365600
 GA90/110/132/160 161937840016136105001614642300
 GA90/110 162105479916210547001614905400
 GA90/110 162157429916136105001621938499
 GA90/110162151070016136105001614905400
GA90/110 from 2009.3162173760016217378001614905400
 GA132/160 1621057499/ 103009790016136105001030097900
 GA132/16016215742991613610500　
GA132/160 from 2009.31621737600 16217378001614905600
GA132/160/1801621510700 16136105001614905600
 GA132+-7.5bar162173769916217378901623051599
 GA160+-7.5bar 162173769916217378901623051499
 GA200/250/315103009790016147273001614704800
GA200/250/315 162105479916147273001614952100
 GA200/250/315162157429916147273001621938699
LS10-25/30/40HP40596250025-52502250121-500
 LS10-25/30/40 NEW02250044-537250025-52502250121-500
 LS10-25/30/4002250131-496250025-525250034-112
 LS12-5002250131-498250025-52602250100-755/ 02250100-756
 LS16-60/7502250131-499250025-526250034-116/ 250042-862
 LS16-60 NEW88290002-337/88290002-338250025-52602250061-137/ 02250061-138
 LS16-75 NEW88290002-337/88290002-338250025-52602250061-137/ 02250061-138
LS16-10002250046-012/02250046-013250025-526 250034-116/ 250042-862
 LS16-100 NEW88290002-337/88290002-338250025-52602250061-137/ 02250061-138
LS20-12502250135-148/409854250025-526 250034-085/ 02250048-734
 LS20-15002250135-148/409854250025-526 250034-085/ 02250048-734
 LS20-150 NEW88290001-469250025-526 250034-085/ 02250048-734
 LS20-175/20002250135-150/ 048463250025-526 250034-122/ 250034-134
 LS20-175/200 NEW88290003-111250025-526 250034-122/ 250034-134
 LS25S-250/300/35088290001-46602250139-996250034-124
 NEW88290001-467　 250034-130
 LS25S-250/300/350250007-838/250007-839 250008-956 250034-124/ 250034-130
 LS3288290004-37202250139-99602250109-319/ 02250109-321
 WS180002250125-371 02250155-709 02250109-319/ 02250109-321
 WS220002250125-371 02250155-709 02250137-895
 WS300002250125-372 02250155-709 02250137-895
 WS370002250127-684 02250155-709 02250100-755/ 02250100-756
Itemsmaintenace actioneverydayeveryweek500h1500h2500h6000h12000h18000h30000h
every monthevery seasonhalf year1 year2 years3 years5 years
The indicator light panelcheck any unusual indicator lightcheck and adjust　　　　　　　　
Discharge temperaturecheck if temperature in 70-95 degree levelcheck and adjust　　　　　　　　
condensed water in oil barreldrain watercheck and adjust　　　　　　　　
oil levelcheckcheck and adjust　　　　　　　　
joint hose for air suctioncheck/replace　　　　check and adjust　　　　
pipeline(rubber/metal pipe)check/replacecheck and adjust　　　　　　replace　
pipeline jointcheck if any leak　　　　　check and adjust　　　
coolerclean　clean　　　　　check and adjust　
cooling fanclean　clean　　　　　　　
air filter for air suctionclean/replace　clean　　replace　　　　
pre-filter netcheck/clean　clean　　　　　　　
Electromagnetic switch contactcheck/clean　clean　　　　　　　
electrical equipment connectadjust　　check and adjust　　　　　　
belt and belt pulleyadjust/replace　　check and adjust　replace　　　　
oil filterreplace　　for new machine　replace　　　　
main motorinject bearing grease　　　check and adjust　　　　　
shaft seal for screw headcheck/replace　　　　check and adjust　　　　
screw compressor oilinject/replace　　for new machine　replace　　　　
oil separatorreplace　　　　replace　　　　
electrical insulationcheck circhurt by multimeter　　　　　check and adjust　　　
thermal control valvecheck/replace　　　　　check and adjust　　　
air suction valvecheck/clean/replace　　　　　check and adjust　　　
min-pressure valvecheck/clean/replace　　　　　check and adjust　　　
safety valvecheck/replace　　　　　check and adjustreplace　　
discharge solenoid valvecheck/clean/replace　　　　check and adjust　　　　
pressure sensorverify check　　　　　check and adjust　　　
temperature sensorverify check　　　　　check and adjust　　　
compressor bearingcheck/replace　　　　　　check and adjust　replace
  • If you don't find the part number you want on our page, please do not hesitate to contact us. We can check it for you. Our factory can also customize unconventional filter elements for you at any time.
How to Buy

How to select the right oil filter

The oil filter protects the bearings and the rotors, so the specification matters more than the price. Ours filters at 5–10 micron with a filtration efficiency of 98 % and a service life of more than 2000 hours.

  • Bypass valve — built in, so that cold oil still reaches the bearings at start-up. A filter without a bypass can starve the airend in cold weather.
  • Media — glass fibre with good water resistance and anti-pulse strength, which is what keeps it intact through load and unload cycles.
  • Selection — by the filter thread on the seat (3/4-16UNF, 1-12UNF, 1-16UNF or M38×1.5) and by the machine model. Thread and burst rating are the two things that must match.

Installation and maintenance

  • Lubricate the gasket with clean oil, fit by hand, then tighten as the filter maker specifies — not with a wrench.
  • Check that the old gasket came away with the old filter. Two gaskets stacked is the most common cause of a leak straight after a change.
  • Change the oil at the same interval. A new filter on old oil simply collects the sludge that the old oil is carrying.
  • Record the hours. The 2000-hour figure assumes normal oil temperature; running above 95 °C shortens it.

Oil filter FAQ

The bypass valve opens and unfiltered oil goes to the bearings. The machine keeps running, which is why a blocked filter is often only discovered when the bearings fail — check the differential or change on hours, do not wait for a symptom.

Not automatically. A finer filter removes more but blocks sooner and costs more pressure drop. Our 5–10 micron range is the normal specification for oil-injected screw compressors.

No. The thread may fit but the bypass pressure and the burst rating are wrong, and the media is not designed for continuous hot oil.

Related parts

Oil filter seat  ·  Oil-gas separator  ·  Air filter
